Product Details:
Payment & Shipping Terms:
|
| Collector-base Voltage: | 50 V | Collector-emitter Voltage: | 45 V |
|---|---|---|---|
| Emitter-base Voltage: | 5 V | Collector Current (DC): | 500 MA |
| Total Power Dissipation: | 625 MW | Junction Temperature: | 150 °C |
| Highlight: | npn smd transistor,multi emitter transistor |
||
BC337 NPN general purpose transistor
FEATURES
• High current (max. 500 mA)
• Low voltage (max. 45 V).
APPLICATIONS
• General purpose switching and amplification, e.g. driver and output stages of audio amplifiers.
DESCRIPTION
NPN transistor in a TO-92; SOT54 plastic package.
PNP complement: BC327.
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC 134).
| SYMBOL | PARAMETER | CONDITIONS | MIN. | MAX. | UNIT |
| VCBO | collector-base voltage | open emitter | − | 50 | V |
| VCEO | collector-emitter voltage | open base | − | 45 | V |
| VEBO | emitter-base voltage | open collector | − | 5 | V |
| IC | collector current (DC) | − | 500 | mA | |
| ICM | peak collector current | − | 1 | A | |
| IBM | peak base current | − | 200 | mA | |
| Ptot | total power dissipation | Tamb ≤ 25 °C; note 1 | − | 625 | mW |
| Tstg | storage temperature | −65 | +150 | °C | |
| Tj | junction temperature | − | 150 | °C | |
| Tamb | operating ambient temperature | −65 | +150 | °C |
Note 1. Transistor mounted on an FR4 printed-circuit board.
PACKAGE OUTLINE
Plastic single-ended leaded (through hole) package; 3 leads SOT54
