BUK9237-55A 3 Pin Transistor N Channel MOS FET TrenchMOS logic level FET

China BUK9237-55A 3 Pin Transistor N Channel MOS FET TrenchMOS logic level FET supplier

Large Image :  BUK9237-55A 3 Pin Transistor N Channel MOS FET TrenchMOS logic level FET

Product Details:

Place of Origin: original factory
Brand Name: Anterwell
Certification: new & original
Model Number: BUK9237-55A

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiate
Packaging Details: Please contact me for details
Delivery Time: 1 day
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 8100pcs
Contact Now
Detailed Product Description
Drain-source Voltage: 55 V Drain-gate Voltage: 55 V
Gate-source Voltage: ±15 V Drain Current: 32 A
Total Power Dissipation: 77 W Package: SOT428 (D-PAK)
High Light:

npn smd transistor

,

multi emitter transistor



Stock Offer (Hot Sell)

Part No. Quantity Brand D/C Package
LD1117S25TR 39000 ST 13+ SOT-223
LD1117S33CTR 32000 ST 16+ SOT-223
LD39015M18R 8024 ST 16+ SOT23-5
LD39300PT33-R 6785 ST 14+ TO-252
LD7531AMGL 16615 LD 16+ SOT23-6
LD7830GR 9996 LD 15+ SOP-8
LDB212G4005C-001 56000 MURATA 14+ SMD
LF25CDT 21498 ST 13+ TO-252
LF347MX 7640 NS 00+ SOP-14
LFB212G45SG8A192 40000 MURATA 16+ SMD
LFCN-400+ 1736 MINI 14+ SMD
LFCN-80+ 3554 MINI 15+ SMD
LFCN-900+ 3324 MINI 15+ SMD
LFE2M100E-6FN900C-5I 256 LATTICE 16+ BGA900
LFXP2-8E-5TN144C 1363 LATTICE 16+ QFP144
LH1518AABTR 3172 VISHAY 04+ SMD-6
LH1520AAC 8563 VISHAY 13+ SOP-8
LH1540AABTR 5958 VISHAY 00+ SOP-6
LH5116NA-10 14603 SHARP 13+ SOP-24
LHI878/3902 14674 HEIMANN 10+ CAN-3
LIS2DH12TR 7611 ST 15+ LGA12
LIS3DHTR 4847 ST 14+ LGA16
LL4004 15000 ST 16+ LL41
LL4148-GS08 45000 VISHAY 15+ LL34
LLQ2012-F56NJ 12000 TOKO 16+ SMD
LM1086CSX-3.3 21569 NS 15+ TO-263
LM1086CT-3.3 15605 NS 15+ TO-220
LM111J-8 5202 NSC 15+ CDIP-8
LM19CIZ 4073 NS 16+ TO-92
LM201AN 4387 ON 16+ DIP-8





BUK9237-55A TrenchMOS™ logic level FET



Description

N-channel enhancement mode field-effect power transistor in a plastic package using TrenchMOS™1 technology, featuring very low on-state resistance.



Product availability: BUK9237-55A in SOT428 (D-PAK).



Features

■ TrenchMOS™ technology

■ Q101 compliant

■ 175 °C rated

■ Logic level compatible.



Applications

■ Automotive and general purpose power switching:

  ◆ 12 V and 24 V loads

  ◆ Motors, lamps and solenoids.



Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134)

Symbol Parameter Conditions Min Max Unit
VDS drain-source voltage (DC)   - 55 V
VDGR drain-gate voltage (DC) RGS = 20 kΩ - 55 V
VGS gate-source voltage (DC)   - ±15 V
ID drain current (DC) Tmb = 25 °C; VGS = 5 V; Figure 2 and 3 - 32 A
Tmb = 100 °C; VGS = 5 V; Figure 2 - 22 A
IDM peak drain current Tmb = 25 °C; pulsed; tp ≤ 10 µs; Figure 3 - 129 A
Ptot total power dissipation Tmb = 25 °C; Figure 1 - 77 W
Tstg storage temperature   -55 +175 °C
Tj operating junction temperature   -55 +175 °C
Source-drain diode
IDR reverse drain current (DC) Tmb = 25 °C - 32 A
IDRM peak reverse drain current Tmb = 25 °C; pulsed; tp ≤ 10 µs - 129 A
Avalanche ruggedness
WDSS non-repetitive avalanche energy

unclamped inductive load; ID = 32 A; VDS ≤ 30 V;

VGS = 5 V; RGS = 50 Ω; starting Tj = 25 °C

- 76 mJ



BUK9237-55A 3 Pin Transistor N Channel MOS FET TrenchMOS logic level FETBUK9237-55A 3 Pin Transistor N Channel MOS FET TrenchMOS logic level FET



Package outline

Plastic single-ended surface mounted package (Philips version of D-PAK); 3 leads

(one lead cropped)                                                                                                  SOT428

BUK9237-55A 3 Pin Transistor N Channel MOS FET TrenchMOS logic level FET

BUK9237-55A 3 Pin Transistor N Channel MOS FET TrenchMOS logic level FET
