K40T1202 Transistor Programmable IC Chip Flash Ic Integrated circuit Chip IC Electronics

K40T1202

100 mA, Adjustable Output, LDO Voltage Regulator with 60 V Load Dump Protection

The LM2931 series consists of positive fixed and adjustable output voltage regulators that are specifically designed to maintain proper regulation with an extremely low input−to−output voltage differential. These devices are capable of supplying output currents in excess of 100 mA and feature a low bias current of 0.4 mA at 10 mA output. Designed primarily to survive in the harsh automotive environment, these devices will protect all external load circuitry from input fault conditions caused by reverse battery connection, two battery jump starts, and excessive line transients during load dump. This series also includes internal current limiting, thermal shutdown, and additionally, is able to withstand temporary power−up with mirror−image insertion. Due to the low dropout voltage and bias current specifications, the LM2931 series is ideally suited for battery powered industrial and consumer equipment where an extension of useful battery life is desirable. The ‘C’ suffix adjustable output regulators feature an output inhibit pin which is extremely useful in microprocessor−based systems.

Features

• Input−to−Output Voltage Differential of < 0.6 V @ 100 mA

• Output Current in Excess of 100 mA

• Low Bias Current

• 60 V Load Dump Protection

• −50 V Reverse Transient Protection

 • Internal Current Limiting with Thermal Shutdown

• Temporary Mirror−Image Protection

• Ideally Suited for Battery Powered Equipment

• Economical 5−Lead TO−220 Package with Two Optional Leadforms

• Available in Surface Mount SOP−8, D2PAK and DPAK Packages

• High Accuracy (±2.5%) Reference (LM2931AC) Available

• Pb−Free Packages are Available

Applications

• Battery Powered Consumer Products

• Hand−held Instruments

• Camcorders and Cameras


DESCRIPTION:

The CENTRAL SEMICONDUCTOR CSHD6-100C is a Silicon Schottky Rectifier designed for surface mount high voltage applications requiring a low forward voltage drop.

MAXIMUM RATINGS: (TC=25°C unless otherwise noted)

 Peak Repetitive Reverse Voltage VRRM 100 V

Average Rectified Forward Current (TC=120°C) IO 6.0 A

Peak Forward Surge Current (tp=10ms) IFSM 50 A

Peak Repetitive Reverse Surge Current (tp=2ms) IRRM 1.0 A

Critical Rate of Rise of Reverse Voltage dv/dt 10,000 V/ms

Operating and Storage Junction Temperature TJ, Tstg -65 to +150 °C

Thermal Resistance QJC 3.5 °C/W
