Product Details:
Payment & Shipping Terms:
|
Maximum Recurrent Peak Reverse Voltage: | 600 Volts | Maximum RMS Voltage: | 420 Volts |
---|---|---|---|
Maximum DC Blocking Voltage: | 600 Volts | Maximum Average Forward Rectified Current At Tc = 125℃: | 2.0 Amps |
Peak Forward Surge Current 8.3 Ms Single Half Sine-wave Superimposed On Rated Load (JEDEC Method): | 60 Amps | Typical Thermal Resistance (Note 2): | 32 / 13 ℃/W |
High Light: | npn smd transistor,multi emitter transistor |
FEATURES
* Ideal for printed circuit board
* Surge overload rating: 60 Amperes peak
* Mounting position: Any
* Weight: 0.15 grams
* RoHS product for packing code suffix "G"
Halogen free product for packing code suffix "H"
MECHANICAL DATA
* UL listed the recognized component directory, file #E195711
* Epoxy: Device has UL flammability classification 94V-O
RATING AND CHARACTERISTIC CURVES
