Product Details:
Payment & Shipping Terms:
|
Repetitive Peak Off-state Voltages: | 650V | Average On-state Current: | 7.5 A |
---|---|---|---|
RMS On-state Current: | 12A | Non-repetitive Peak On-state Current: | 100A |
Peak Gate Current: | 2A | Peak Gate Voltage: | 5V |
High Light: | npn smd transistor,silicon power transistors |
GENERAL DESCRIPTION
Glasspassivated thyristors ina plastic
envelope, intended for use in
applications requiring high
bidirectional blocking voltage
capability and high thermal cycling
performance. Typical applications
include motor control, industrial and
domestic lighting, heating and static
switching.
QUICK REFERENCE DATA
SYMBOL | PARAMETER | MAX. | MAX. | MAX. | UNIT |
BT151- |
500R | 650R | 800R | ||
VDRM, VRRM |
Repetitive peak off-state voltages |
500 | 650 | 800 | V |
IT(AV) | Average on-state current | 7.5 | 7.5 | 7.5 | A |
IT(RMS) | RMS on-state current | 12 | 12 | 12 | A |
ITSM |
Non-repetitive peak on-state current |
100 | 100 | 100 | A |
PINNING - TO220AB PIN CONFIGURATION SYMBOL
PIN | DESCRIPTION |
1 | cathode |
2 | anode |
3 | gate |
tab | anode |
