IEC Appliance Inlet C16 Screw-on Mounting Front Side Quick connect or Screw-on Terminal 0161

: Large Image : IEC Appliance Inlet C16 Screw-on Mounting Front Side Quick connect or Screw-on Terminal 0161

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	0161

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	3800pcs

Contact Now

Detailed Product Description

Pin Temperature:	120 °C	Ratings IEC:	10A / 250VAC; 50Hz
Ratings UL/CSA:	15A / 250VAC; 60Hz	Degree Of Protection:	From Front Side IP 20 Acc. To IEC 60529
Allowable Operation Temp.:	-25°C To 120°C	Material: Housing:	Black Or Grey, UL 94V-0
High Light:	low voltage power mosfet , hybrid inverter circuit

IEC Appliance Inlet C16, Screw-on Mounting, Front Side, Quick-connect or Screw-on Terminal

Description

- Panel Mount: Screw-on mounting, Frontside

- Appliance Inlet, Pin temperature 120 °C, Protection class I

Approvals

- VDE License Number: 40009508

- UL License Number: E96454

- CSA License Number: 27324

Technical Data

Ratings IEC	10A / 250VAC; 50Hz
Ratings UL/CSA	15A / 250VAC; 60Hz
Dielectric Strength	> 3kVAC between L-N > 1.5kVAC between L/N-PE (1min/50Hz)
Allowable Operation Temp.	-25°C to 120°C
Degree of Protection	from front side IP 20 acc. to IEC 60529
Protection Class	Suitable for appliances with protection class 1 acc. to IEC 61140
Material: Housing	black or grey, UL 94V-0
Appliance Inlet	C16 acc. to IEC/EN 60320-1 UL 498, CSA C22.2 no. 42 (For hot conditions) pin-temperature 120 °C, 10A, Protection Class 1

Dimensions

IEC Appliance Inlet C16 Screw-on Mounting Front Side Quick connect or Screw-on Terminal 0161

Variants

Config. Code	Description	Order Number
0161-X-8880-A-136	0161, IEC Appliance Inlet C16, 120°C, version: 1, L: blade terminal (4,8x0,8mm), N: blade terminal (4,8x0,8mm), ground: blade terminal (4,8x0,8mm), color: jet black; RAL9005, design: flange with countersunk holes, dimension X: 36	0161 (1207752714813)
0161-X-9990-A-136	0161, IEC Appliance Inlet C16, 120°C, version: 1, L: blade terminal (6,3x0,8mm), N: blade terminal (6,3x0,8mm), ground: blade terminal (6,3x0,8mm), color: jet black; RAL9005, design: flange with countersunk holes, dimension X: 36	0161 (1207752795779)
