Surface mount Si-Epitaxial PlanarTransistors BCP53

: Large Image : Surface mount Si-Epitaxial PlanarTransistors BCP53

Product Details:

Place of Origin:	original factory
Brand Name:	anterwell
Certification:	new & original
Model Number:	BCP53

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, PayPal
Supply Ability:	1000pcs

Contact Now

Detailed Product Description

Power Dissipation – Verlustleistung:	1.3 W	Collector Current – Kollektorstrom (DC):	1 A
Peak Collector Current – Koll.-Spitzenstrom:	1.5 A	Peak Base Current – Basis-Spitzenstrom:	200 MA
Junction Temperature – Sperrschichttemperatur:	150℃	Storage Temperature – Lagerungstemperatur:	- 65…+ 150℃
High Light:	npn smd transistor , multi emitter transistor

Power dissipation – Verlustleistung 1.3 W Surface mount Si-Epitaxial PlanarTransistors BCP53

Plastic case SOT-223

Kunststoffgehäuse

Weight approx. – Gewicht ca. 0.04 g

Plastic material has UL classification 94V-0

Gehäusematerial UL94V-0 klassifiziert

Standard packaging taped and reeled

Standard Lieferform gegurtet auf Rolle

Maximum ratings (T_A = 25℃) Grenzwerte (T_A = 25℃)

		BCP 51	BCP 52	BCP 53
Collector-Emitter-voltage B open	- V_CE0	45 V	60 V	80 V
Collector-Base-voltage E open	- V_CB0	45 V	60 V	100 V
Emitter-Base-voltage C open	- V_EB0	5 V
Power dissipation – Verlustleistung	P_tot	1.3 W ¹)
Collector current – Kollektorstrom (DC)	- I_C	1 A
Peak Collector current – Koll.-Spitzenstrom	- I_CM	1.5 A
Peak Base current – Basis-Spitzenstrom	- I_BM	200 mA
Junction temperature – Sperrschichttemperatur	T_j	150℃
Storage temperature – Lagerungstemperatur	T_S	- 65…+ 150℃

¹) Mounted on P.C. board with 3 mm² copper pad at each terminal

Montage auf Leiterplatte mit 3 mm² Kupferbelag (Lötpad) an jedem Anschluß

Surface mount Si-Epitaxial PlanarTransistors BCP53
