PNP Silicon Amplifier Transistor 625mW BC557A

: Large Image : PNP Silicon Amplifier Transistor 625mW BC557A

Product Details:

Place of Origin:	original factory
Brand Name:	anterwell
Certification:	new & original
Model Number:	BC557A

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, PayPal
Supply Ability:	20000pcs

Contact Now

Detailed Product Description

Feature 1:	Lead Free Finish/RoHS Compliant	Feature 2:	150°C Junction Temperature
Feature 3:	Through Hole Package	Feature 4:	Epoxy Meets UL 94 V-0 Flammability Rating
Feature 5:	Moisure Sensitivity Level 1	Marking:	Type Number
Highlight:	npn smd transistor , multi emitter transistor

Features

• Lead Free Finish/RoHS Compliant ("P" Suffix designates

RoHS Compliant. See ordering information)

• 150o C Junction Temperature

• Through Hole Package

• Epoxy meets UL 94 V-0 flammability rating

• Moisure Sensitivity Level 1

• Marking:Type Number

Mechanical Data

• Case: TO-92, Molded Plastic

• Polarity: indicated as below.

Maximum Ratings @ 25o C Unless Otherwise Specified

Charateristic	Symbol	Value	Unit
Collector-Emitter Voltage BC556 BC557 BC558	V_CEO	-65 -45 -30	V
Collector-Base Voltage BC556 BC557 BC558	V_CBO	-80 -50 -30	V
Emitter-Base Voltage	V_EBO	-5.0	V
Collector Current(DC)	I_C	-100	mA
Power Dissipation@T_A=25°C	P_d	625 5.0	mW mW/°C
Power Dissipation@T_C=25°C	P_d	1.5 12	mW mW/°C
Thermal Resistance, Junction to Ambient Air	R _JA	200	°C/W
Thermal Resistance, Junction to Case	R _JC	83.3	°C/W
Operating & Storage Temperature	T_j , T_STG	-55~150	°C
