Power Mosfet Ic 2SA1837 Power Mosfet Transistor Silicon PNP Power Transistors

: Large Image : Power Mosfet Ic 2SA1837 Power Mosfet Transistor Silicon PNP Power Transistors

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	2SA1837

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	10000pcs

Contact Now

Detailed Product Description

Collector-base Voltage:	-230 V	Collector-emitter Voltage:	-230 V
Emitter-base Voltage:	-5 V	Collector Current:	-1 A
Base Current:	-0.1 A	Junction Temperature:	150 ℃
Highlight:	power mosfet ic , silicon power transistors

Silicon PNP Power Transistors 2SA1837

DESCRIPTION

·With TO-220F package

·Complement to type 2SC4793

·High transition frequency

APPLICATIONS

·Power amplifier applications

·Driver stage amplifier applications

PINNING

PIN	DESCRIPTION
1	Base
2	Collector
3	Emitter

Absolute maximum ratings (Ta=25℃)

SYMBOL	PARAMETER	CONDITIONS	VALUE	UNIT
V_CBO	Collector-base voltage	Open emitter	-230	V
V_CEO	Collector-emitter voltage	Open base	-230	V
V_EBO	Emitter-base voltage	Open collector	-5	V
I_C	Collector current		-1	A
I_B	Base current		-0.1	A
P_C	Collector dissipation	T_C=25℃	20	W
P_C	Collector dissipation	Ta=25℃	2.0	W
Tj	Junction temperature		150	℃
Tstg	Storage temperature		-55~150	℃

PACKAGE OUTLINE

Power Mosfet Ic 2SA1837 Power Mosfet Transistor Silicon PNP Power Transistors
