PESD12VL1BA Rectifier Diode Low capacitance bidirectional ESD protection diodes

: Large Image : PESD12VL1BA Rectifier Diode Low capacitance bidirectional ESD protection diodes

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	PESD12VL1BA

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	20000pcs

Contact Now

Detailed Product Description

Reverse Stand-off Voltage:	12 V	Reverse Leakage Current:	50 NA
Breakdown Voltage:	15.9 V	Diode Capacitance:	19 PF
Junction Temperature:	150 °C	Storage Temperature:	−65 To +150 °C
Highlight:	diode rectifier circuit , bridge rectifier circuit

PESDxL1BA series

Low capacitance bidirectional ESD protection diodes in SOD323

General description

Bidirectional ElectroStatic Discharge (ESD) protection diodes in a very small SOD323 (SC-76) SMD plastic package designed to protect one signal line from the damage caused by ESD and other transients.

Features

■ Bidirectional ESD protection of one line

■ ESD protection > 23 kV

■ Max. peak pulse power: P_pp = 500 W

■ IEC 61000-4-2, level 4 (ESD)

■ Low clamping voltage: V_(CL)R = 26 V

■ IEC 61000-4-5 (surge); I_pp = 18 A

■ Ultra low leakage current: I_RM < 0.09 µA

■ Very small SMD plastic package.

Applications

■ Computers and peripherals

■ Data lines

■ Communication systems

■ CAN bus protection.

■ Audio and video equipment

Pinning

PESD12VL1BA Rectifier Diode Low capacitance bidirectional ESD protection diodes

Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134).

Symbol	Parameter	Conditions	Min	Max	Unit
P_pp	peak pulse power	8/20 µs ^[1]
	PESD3V3L1BA		-	500	W
	PESD5V0L1BA		-	500	W
	PESD12VL1BA		-	200	W
	PESD15VL1BA		-	200	W
	PESD24VL1BA		-	200	W
I_pp	peak pulse current	8/20 µs ^[1]
	PESD3V3L1BA		-	18	A
	PESD5V0L1BA		-	15	A
	PESD12VL1BA		-	5	A
	PESD15VL1BA		-	5	A
	PESD24VL1BA		-	3	A
Tj	junction temperature		-	150	°C
Tamb	ambient temperature		−65	+150	°C
Tstg	storage temperature		−65	+150	°C

[1] Non-repetitive current pulse 8/20 µs exponential decay waveform; see Figure 1.
