ULN2803ADWR Integrated Circuit Chip DARLINGTON TRANSISTOR ARRAY

ULN2803A

DARLINGTON TRANSISTOR ARRAY

•
500-mA Rated Collector Current (Single Output)

•
High-Voltage Outputs . . . 50 V

•
Output Clamp Diodes

•
Inputs Compatible With Various Types of Logic

•
Relay Driver Applications

•
Compatible with ULN2800A Series

description

The ULN2803A is a high-voltage, high-current Darlington transistor array. The device consists of eight npn Darlington pairs that feature high-voltage outputs with common-cathode clamp diodes for switching inductive loads. The collector-current rating of each Darlington pair is 500 mA. The Darlington pairs may be connected in parallel for higher current capability.

Applications include relay drivers, hammer drivers, lamp drivers, display drivers (LED and gas discharge), line drivers, and logic buffers. The ULN2803A has a 2.7-kΩ series base resistor for each Darlington pair for operation directly with TTL or 5-V CMOS devices.

absolute maximum ratings at 25°C free-air temperature (unless otherwise noted)†

Collector-emitter voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 V

Input voltage (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 V

Continuous collector current  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500 mA

Output clamp diode current  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500 mA

Total substrate-terminal current  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −2.5 A

Package thermal impedance, θ_JA (see Notes 2 and 3): DW package  . . . . . . . . . . 73.14°C/W

                                                                                      N package  . . . . . . . . . . . . 62.66°C/W

Operating virtual junction temperature, T_J  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150°C

Storage temperature range, Tstg  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −65°C to 150°C

†Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

NOTES:

1. All voltage values, unless otherwise noted, are with respect to the emitter/substrate terminal GND.

2. Maximum power dissipation is a function of TJ(max), θJA, and TA. The maximum allowable power dissipation at any allowable ambient temperature is PD = (TJ(max) − TA)/θJA. Operating at the absolute maximum TJ of 150°C can affect reliability.

3. The package thermal impedance is calculated in accordance with JESD 51-7.
