VCC: | ....................................................................-0.3V To +6.0V | RESET, RESET (push-pull): | .....................-0.3V To (VCC + 0.3V) |
---|---|---|---|
Input Current, VCC: | ..............................................................20mA | Output Current, RESET, RESET: | ..........................................20mA |
Rate Of Rise, VCC: | ............................................................100V/µs | ||
High Light: | bridge rectifier circuit,signal schottky diode |
♦ Precision Monitoring of +2.5V, +3V, +3.3V, and +5V Power-Supply Voltages
♦ Fully Specified Over Temperature
♦ Available in Three Output Configurations Open-Drain RESET Output (MAX803) Push-Pull RESET Output (MAX809) Push-Pull RESET Output (MAX810)
♦ 140ms min Power-On Reset Pulse Width
♦ 12µA Supply Current
♦ Guaranteed Reset Valid to VCC = +1V
♦ Power Supply Transient Immunity
♦ No External Components
♦ 3-Pin SC70 and SOT23 Packages
The MAX803/MAX809/MAX810 are microprocessor (µP) supervisory circuits used to monitor the power supplies in µP and digital systems. They provide excellent circuit reliability and low cost by eliminating external components and adjustments when used with +5V, +3.3V, +3.0V, or +2.5V-powered circuits.
These circuits perform a single function: they assert a reset signal whenever the VCC supply voltage declines below a preset threshold, keeping it asserted for at least 140ms after VCC has risen above the reset threshold. Reset thresholds suitable for operation with a variety of supply voltages are available.
The MAX803 has an open-drain output stage, while the MAX809/MAX810 have push-pull outputs. The MAX803’s open-drain RESET output requires a pull-up resistor that can be connected to a voltage higher than VCC. The MAX803/MAX809 have an active-low RESET output, while the MAX810 has an active-high RESET output. The reset comparator is designed to ignore fast transients on VCC, and the outputs are guaranteed to be in the correct logic state for VCC down to 1V.
