22V10ACFN High Performance Impact E Programmable Array Logic Circuits

22V10ACFN HIGH-PERFORMANCE IMPACT E PROGRAMMABLE ARRAY LOGIC CIRCUITS

•Second-Generation PLD Architecture

• Choice of Operating Speeds

TIBPAL22V10AC . . . 25 ns Max

TIBPAL22V10AM . . . 30 ns Max

TIBPAL22V10C . . . 35 ns Max

• Increased Logic Power – Up to 22 Inputs and 10 Outputs

• Increased Product Terms – Average of 12 Per Output

• Variable Product Term Distribution Allows More Complex Functions to Be Implemented

• Each Output Is User Programmable for Registered or Combinational Operation, Polarity, and Output Enable Control

• TTL-Level Preload for Improved Testability

• Extra Terms Provide Logical Synchronous Set and Asynchronous Reset Capability

absolute maximum ratings over operating free-air temperature range (unless otherwise noted)

Supply voltage, VCC (see Note 1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . 7 V

Input voltage (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –5.5 V Voltage range applied to disabled output (see Note 1). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.5 V Operating free-air temperature range  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0°C to 75°C Storage temperature range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65°C to 150°C

functional block diagram (positive logic)
