S3G-E3/57T Rectifier Diode Surface Mount Ultrafast Plastic Rectifier

: Large Image : S3G-E3/57T Rectifier Diode Surface Mount Ultrafast Plastic Rectifier

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	S3G-E3/57T

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	12000pcs

Contact Now

Detailed Product Description

Maximum Instantaneous Forward Voltage:	1.1 V	Maximum Reverse Recovery Current:	3.0 A
Maximum Stored Charge:	50 NC	Typical Junction Capacitance:	30 PF
Maximum RMS Voltage:	280 V	Operating Junction And Storage Temperature:	- 55 To + 150 °C
High Light:	bridge rectifier circuit , signal schottky diode

ES3F & ES3G

Surface Mount Ultrafast Plastic Rectifier

S3G-E3/57T Rectifier Diode Surface Mount Ultrafast Plastic Rectifier

FEATURES

• Glass passivated chip junction

• Ideal for automated placement

• Ultrafast reverse recovery time

• Low switching losses, high efficiency

• High forward surge capability

• Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C

• Solder dip 260 °C, 40 s

• Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC

TYPICAL APPLICATIONS

For use in high frequency rectification and freewheeling application in switching mode converters and inverters for consumer, computer and telecommunication.

MECHANICAL DATA

Case: DO-214AB (SMC)

Epoxy meets UL 94V-0 flammability rating

Terminals: Matte tin plated leads, solderable per J-STD-002 and JESD22-B102

E3 suffix for consumer grade, meets JESD 201 class 1A whisker test, HE3 suffix for high reliability grade (AEC Q101 qualified), meets JESD 201 class 2 whisker test

Polarity: Color band denotes cathode end

PRIMARY CHARACTERISTICS

I_F(AV)	3.0 A
V_RRM	300 V, 400 V
I_FSM	100 A
t_rr	35 ns
V_F	1.1 V
T_J max	150 °C

MAXIMUM RATINGS (T_A = 25 °C unless otherwise noted)

PARAMETER	SYMBOL	ES3F	ES3G	UNIT
Device marking code		EF	EG
Maximum repetitive peak reverse voltage	V_RRM	300	400	V
Working peak reverse voltage	V_RWM	225	300	V
Maximum RMS voltage	V_RMS	210	280	V
Maximum average forward rectified current at T_L = 110 °C	I_F(AV)	3.0		A
Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load	I_FSM	100		A
Operating junction and storage temperature range	T_J, T_STG	- 55 to + 150		°C

PACKAGE OUTLINE DIMENSIONS in inches (millimeters)

S3G-E3/57T Rectifier Diode Surface Mount Ultrafast Plastic Rectifier
