Overview

! Case: SMC/DO-214AB, Molded Plastic

! Terminals: Solder Plated, Solderable per MIL-STD-750, Method 2026

! Polarity: Cathode Band or Cathode Notch

! Marking: Type Number ! Weight: 0.21 grams (approx.)

! Lead Free: For RoHS / Lead Free Version, Add “-LF” Suffix to Part Number, See Page 4

Functions

! Glass Passivated Die Construction

! Ideally Suited for Automatic Assembly B

! Low Forward Voltage Drop

! Surge Overload Rating to 100A Peak D

! Low Power Loss A

! Built-in Strain Relief F

! Plastic Case Material has UL Flammability Classification Rating 94V-O

Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage

VRRM VRWM VR 50 100 200 400 600 800 1000 V RMS

Reverse Voltage VR(RMS) 35 70 140 280 420 560 700 V

Average Rectified Output Current @TL = 75°C IO 5.0 A

Non-Repetitive Peak Forward Surge Current 8.3ms

Single half sine-wave superimposed on rated load (JEDEC Method) IFSM 100 A

Forward Voltage @IF = 5.0A VFM 1.15 V

Peak Reverse Current @TA = 25°C

At Rated DC Blocking Voltage @TA = 125°C

IRM 10 250 µA Typical Junction Capacitance (Note 1) Cj 40 pF

Typical Thermal Resistance (Note 2) R
JL 10 °C/W

Operating and Storage Temperature Range Tj, TSTG -65 to +150 °C
