2SD669A High Power Mosfet Transistors Silicon NPN Power Transistors

: Large Image : 2SD669A High Power Mosfet Transistors Silicon NPN Power Transistors

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	2SD669A

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	7600pcs

Contact Now

Detailed Product Description

Collector-base Voltage:	180 V	Collector-emitter Voltage:	160 V
Emitter-base Voltage:	5 V	Collector Current (DC):	1.5 A
Collector Current-peak:	3 A	Junction Temperature:	150 ℃
High Light:	power mosfet ic , silicon power transistors

Silicon NPN Power Transistors 2SD669 2SD669A

DESCRIPTION

·With TO-126 package

·Complement to type 2SB649/649A

·High breakdown voltage V_CEO:120/160V

·High current 1.5A

·Low saturation voltage,excellent h_FE linearity

APPLICATIONS

·For low-frequency power amplifier applications

Absolute maximum ratings(Ta=25℃)

SYMBOL	PARAMETER		CONDITIONS	VALUE	UNIT
V_CBO	Collector-base voltage	2SD669	Open emitter	180	V
V_CBO	Collector-base voltage	2SD669A	Open emitter	180	V
V_CEO	Collector-emitter voltage	2SD669	Open base	120	V
V_CEO	Collector-emitter voltage	2SD669A	Open base	160	V
V_EBO	Emitter-base voltage		Open collector	5	V
I_C	Collector current (DC)			1.5	A
I_CM	Collector current-peak			3	A
P_D	Total power dissipation		Ta=25℃	1	W
P_D	Total power dissipation		T_C=25℃	20	W
Tj	Junction temperature			150	℃
Tstg	Storage temperature			-55~150	℃

PACKAGE OUTLINE

2SD669A High Power Mosfet Transistors Silicon NPN Power Transistors
