1N5821RLG Rectifier Diode 730nm diode laser Axial Lead Rectifiers

: Large Image : 1N5821RLG Rectifier Diode 730nm diode laser Axial Lead Rectifiers

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	1N5821RLG

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	10000pcs

Contact Now

Detailed Product Description

Peak Repetitive Reverse Voltage:	30 V	Working Peak Reverse Voltage:	30 V
DC Blocking Voltage:	30 V	RMS Reverse Voltage:	21 V
Average Forward Rectified Current:	3.0 A	Typical Junction Capacitance:	250 PF
High Light:	diode rectifier circuit , signal schottky diode

3.0 Amp BARRIER SCHOTTKY RECTIFIERS

Features

EXTREMELY LOW VF
LOW POWER LOSS HIGH EFFICIENCY
LOW STORED CHARGE; MAJORITY CARRIER CONDUCTION
MEETS UL SPECIFICATION 94V-0

Electrical Characteristics @ 25℃

Maximum Ratings	IN5820	IN5821	IN5822	Units
Peak Repetitive Reverse Voltage...V_RRM	20	30	40	Volts
Working Peak Reverse Voltage...V_RWM	20	30	40	Volts
DC Blocking Voltage...V_DC	20	30	40	Volts
RMS Reverse Voltage...V_R(rms)	14	21	28	Volts
Average Forward Rectified Current...I_F(av) @ T_A= 55°C	3.0			Amps
Non-Repetitive Peak Forward Surge Current...I_FSM @ Rated Load Conditions, ½ Wave, 60 HZ, T_L = 75°C	80			Amps
Forward Voltage...V_F @ I_F = 3.0 Amps	475	500	525	Volts
DC Reverse Current...I_R @ Rated DC Blocking Voltage T_L = 25°C T_L = 100°C	2.0 10			mAmps mAmps
Typical Junction Capacitance...C_J	250			pF
Operating & Storage Temperature Range...T_J, T_STRG	-65 to 125			°C

1N5821RLG Rectifier Diode 730nm diode laser Axial Lead Rectifiers
