Product Details:
Payment & Shipping Terms:
|
| RthJA: | 170 K/W | Junction Temperature: | 150 °C |
|---|---|---|---|
| Storage Temperature: | 65 To + 150 °C | VS Or VD To V+: | …0, -40V |
| VS Or VD To V-: | .0, 40V | ||
| Highlight: | bridge rectifier circuit,signal schottky diode |
||
Features
• Silicon Planar Power Zener Diodes
• For use in stablilizing and clipping circuits with high power rating
• Standard Zener voltage tolerance is ± 5 %
• These diodes are also available in the DO-41 case with type designation 1N4728 A... 1N4764A
• Lead (Pb)-free component
• Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC
Mechanical Data
Case: MELF Glass case Weight: approx. 135 mg
Packaging Codes/Options: GS18 / 5 k per 13" reel (8 mm tape), 10 k/box GS08 / 1.5 k per 7" reel (8 mm tape), 12 k/box
Thermal Characteristics
Tamb = 25 °C, unless otherwise specified
| Parameter | Symbol | Value | Unit |
| Thermal resistance junction to ambient air | RthJA | 1701) | K/W |
| Junction temperature | Tj | 150 | °C |
| Storage temperature | Tstg | -65 to + 150 | °C |
Package Dimensions in mm (Inches)
