P6SMB Series
600W Surface Mount Transient Voltage Suppressors
Peak Pulse Power 600 Watt
Stand-off Voltage 6.8 To 550 VOLTS
Feature:
* 600 Watt Peak Power Dissipation
* Glass Passivated Die Construction
* Excellent Clamping Capability Fast Response Time
* Plastic Material Has UL Flammability Classification Rating 94V-O
Mechanical Data
* Case:Transfer Molded Epoxy
* Polarity: Indicator by Cathode Band (Bi-directional Devices Has no Polarity Indicator)
* Terminals: Solderable per MIL-STD-202 Method 208
* Weight: 0.1grams(approx)
Maximum Ratings
Characteristics | Symbol | Value | Unit |
Peak Pulse Power Dissipation on 10/1000us Waveform(1)(2)(FIG1) | PPPM | 600 | W |
Peak Pulse Current of on 10/1000us Waveform(1)(FIG3) | IPPM | see Table | A |
Peak Forward Surge Current 8.3ms Single Half Sine-Wave, Superimposed on Rated Load(JEDEC Method)(3) | IFSM | 100 | A |
Operating and Storage Junction Temperature Range | Tj,TSTG | -55 to -150 | ℃ |
NOTE:
1. Non-Repetitive Current Pulse, per FIG3 and Derated
2. Mounted on 5.0mm Copper Pads to each Terminal
3. 8.3ms Single Half Sine-Wave, or equivalent Square above TA=25 C per FIG2 Wave, Duty Cycle=4 pulses per minutes Maximum.
SMB Outline Dimension Unit:mm
High Power Rectifier Diode 1N4756A , Silicon Planar Zener Diodes
Bridge Type Rectifier Diode 1N4007 50 to 1000 Volts 1.0 Ampere
1N4742A Silicon Planar Zener Diodes for Stabilized Power Supply
