FEATURES
• Wide Input Voltage Range: 5.5 V to 36 V
• Up to 3-A Continuous (4-A Peak) Output Current
•High Efficiency up to 95% Enabled by 110-mΩ Integrated MOSFET Switch
•Wide Output Voltage Range: Adjustable Down to 1.22 V with 1.5% Initial Accuracy
• Internal Compensation Minimizes External Parts Count
• Fixed 500 kHz Switching Frequency for Small Filter Size
•Improved Line Regulation and Transient Response by Input Voltage Feed Forward
• System Protected by Over Current Limiting and Thermal Shutdown
• –40°C to 125°C Operating Junction Temperature Range
DESCRIPTION
The TPS5430 device is available in a thermally www.ti.com/swift enhanced, easy to use 8-pin SOIC PowerPAD™ package. TI provides evaluation modules and the SWIFT™ Designer software tool to aid in quickly achieving high-performance power supply designs to meet aggressive equipment development cycles.
Application Circuits
Figure 11 shows the schematic for a typical TPS5430 application. The TPS5430 can provide up to 3-A output current at a nominal output voltage of 5.0 V. For proper thermal performance the exposed PowerPAD underneath the device must be soldered down to the printed circuit board.
