Product Details:
Payment & Shipping Terms:
|
| Maximum Power Dissipation: | 500 MW | Nominal Z-voltage Nominale Z-Spannun: | 1...75 V |
|---|---|---|---|
| Glass Case MiniMELF Glasgehäuse MiniMELF: | SOD-80C | Weight Approx. Gewicht Ca.: | 0.04 G |
| High Light: | diode rectifier circuit,bridge rectifier circuit |
||
FEATURES :
• Silicon planar zener diodes
• In MiniMELF case especially for automatic insertion
• Standard zener voltage tolerance is ± 5%
• Other zener voltages are available upon request.
• These diodes are also available in DO-35 case
with the type designation ZPD2.7 ... ZPD51
• Pb / RoHS Free
MECHANICAL DATA :
* Case : MiniMELF Glass Case (SOD-80C)
* Weight : 0.05 gram (approximately)
Maximum Ratings and Thermal Characteristics
Rating at 25 °C ambient temperature unless otherwise specified.
| Parameter | Symbol | Value | Unit |
| Zener Current see Table "Characteristics" | |||
| Maximum Forward Voltage at IF = 200 mA. | VF | 1.25 | V |
| Power Dissipation at Tflange = 75°C | PD | 500(1) | mW |
| Thermal Resistance Junction to Ambient Air | RqJA | 300(1) | °C/W |
| Junction temperature | TJ | 175 | °C |
| Storage temperature range | TS | -65 to + 150 | °C |
