DS36C279MX Low Power EIA-RS-485 Transceiver with Sleep Mode led circuit board printed circuit board

China DS36C279MX  Low Power EIA-RS-485 Transceiver with Sleep Mode led circuit board printed circuit board supplier

Large Image :  DS36C279MX Low Power EIA-RS-485 Transceiver with Sleep Mode led circuit board printed circuit board

Product Details:

Place of Origin: Original
Brand Name: NSC
Certification: Original Factory Pack
Model Number: DS36C279MX

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: please contact me for details
Delivery Time: 1 Day
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 290PCS
Contact Now
Detailed Product Description
Supply Voltage (VCC): +12V Nput Voltage (DE, RE*, & DI): −0.5V To (VCC +0.5V)
Driver Output/Receiver Input: ±15V Input Voltage (DO/RI, DO*/RI*): ±14V
Receiver Output Voltage: −0.5V To (VCC +0.5V)
High Light:

electronics ic chip

,

integrated circuit ic


DS36C279MX Low Power EIA-RS-485 Transceiver with Sleep Mode

led circuit board printed circuit board


DS36C279MX  Low Power EIA-RS-485 Transceiver with Sleep Mode led circuit board printed circuit boardFeatures

► 100% RS-485 compliant

— Guaranteed RS-485 device interoperation

► Low power CMOS design: ICC 500 µA max

► Automatic sensing sleep mode — Reduces ICC to 10 µA maximum

► Built-in power up/down glitch-free circuitry

— Permits live transceiver intersection/displacement

► DIP and SOIC packages available

► Industrial temperature range: −40˚C to +85˚C

► On-board thermal shutdown circuitry

— Prevents damage to the device in the event of excessive power dissipation

► Wide common mode range: −7V to +12V

► Receive open input fail-safe (Note 1)

► 1⁄4 unit load (DS36C279): ≥ 128 nodes

► 1⁄2 unit load (DS36C279T): ≥ 64 nodes

► Drop-in replacement for:

— LTC485 MAX485 DS75176 DS3695



General Description

The DS36C279 is a low power differential bus/line transceiver designed to meet the requirements of RS-485 Standard for multipoint data transmission. In addition it is compatible with TIA/EIA-422-B.



The sleep mode feature automatically puts the device in a power saving mode when both the driver and receiver are disabled.†† The device is ideal for use in power conscious applications where the device may be disabled for extended periods of time.



The driver and receiver outputs feature TRI-STATE® capability. The driver outputs operate over the entire common mode range of −7V to +12V. Bus contention or fault situations that cause excessive power dissipation within the device are handled by a thermal shutdown circuit, which forces the driver outputs into a high impedance state



The receiver incorporates a fail safe circuit which guarantees a high output state when the inputs are left open.† The DS36C279T is fully specified over the industrial temperature range (−40˚C to +85˚C).



DS36C279MX  Low Power EIA-RS-485 Transceiver with Sleep Mode led circuit board printed circuit board
