LM2936MP-3.3 Ultra-Low Quiescent Current LDO Voltage Regulator

Stock List

LM2936MP-3.3 Ultra-Low Quiescent Current LDO Voltage Regulator

Features

► Ultra low quiescent current (IQ ≤ 15 µA for IO = 100 µA)

► Fixed 3.0V, 3.3V or 5.0V with 50 mA output

► ±2% Initial output tolerance

► ±3% Output tolerance over line, load, and temperature

► Dropout voltage typically 200 mV @ IO = 50 mA

► Reverse battery protection

► −50V reverse transient protection

► Internal short circuit current limit

► Internal thermal shutdown protection

► 40V operating voltage limit

► 60V operating voltage limit for LM2936HV

► Shutdown Pin available with LM2936BM package

General Description

The LM2936 ultra-low quiescent current regulator features low dropout voltage and low current in the standby mode. With less than 15 µA quiescent current at a 100 µA load, the LM2936 is ideally suited for automotive and other battery operated systems. The LM2936 retains all of the features that are common to low dropout regulators including a low dropout PNP pass device, short circuit protection, reverse battery protection, and thermal shutdown. The LM2936 has a 40V maximum operating voltage limit, a −40˚C to +125˚C operating temperature range, and ±3% output voltage tolerance over the entire output current, input voltage, and temperature range. The LM2936 is available in a TO-92 package, SO-8 and SOT–23 surface mount packages, and a TO-252 surface mount power package.
