L6219DS013TR Stepper motor driver electronic chip board computer chip board

China L6219DS013TR Stepper motor driver  electronic chip board computer chip board supplier

Large Image :  L6219DS013TR Stepper motor driver electronic chip board computer chip board

Product Details:

Place of Origin: Original
Brand Name: STMICROELECTRONICS
Certification: Original Factory Pack
Model Number: L6219DS013TR

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: please contact me for details
Delivery Time: 1 Day
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 290PCS
Contact Now
Detailed Product Description
Supply Voltage: 50 V Output Current (peak): ±1 A
Output Current (continuous): ±0.75 A Logic Supply Voltage: 7 V
Logic Input Voltage Range: -0.3 To +7 V
High Light:

electronic chip board

,

electronic components ic


Stepper motor driver


L6219DS013TR Stepper motor driver  electronic chip board computer chip board

Features
■ Able to drive both windings of bipolar stepper motor
■ Output current up to 750 mA each winding
■ Wide voltage range: 10 V to 46 V
■ Half-step, full-step and microstepping mode
■ Built-in protection diodes
■ Internal PWM current control
■ Low output saturation voltage
■ Designed for unstabilized motor supply voltage
■ Internal thermal shutdown

Description
The L6219 is a bipolar monolithic integrated circuits intended to control and drive both winding of a bipolar stepper motor or bidirectionally control two DC motors.

The L6219 with a few external components form a complete control and drive circuit for LS-TTL or microprocessor controlled stepper motor system. The power stage is a dual full bridge capable of sustaining 46V and including four diodes for current recirculation.

A cross conduction protection is provided to avoid simultaneous cross conduction during switching current direction.

An internal pulse-width-modulation (PWM) controls the output current to 750 mA with peak startup current up to 1 A.

Wide range of current control from 750 mA (each bridge) is permitted by means of two logic inputs and an external voltage reference. A phase input to each bridge determines the load current direction. A thermal protection circuitry disables the outputs if the chip temperature exceeds safe operating limits.


Block diagram
