AK4430ETP-E2 electronics ic chips , Integrated circuit Chip 3.0V - 3.6V

AK4430ETP-E2 electronics ic chips , Integrated circuit Chip 3.0V - 3.6V

GENERAL DESCRIPTION The AK4430 is 3.3V 24-bit stereo DAC with an integrated 2Vrms output buffer. A charge pump in the buffer develops an internal negative power supply rail that enables a ground-referenced 2Vrms output. Using AKM’s multi bit modulator architecture, the AK4430 delivers a wide dynamic range while preserving linearity for improved THD+N performance. The AK4430 integrates a combination of switched-capacitor and continuous-time filters, increasing performance for systems with excessive clock jitter. The 24-bit word length and 192kHz sampling rate make this part ideal for a wide range of consumer audio applications, such as portable A/V players, set-top boxes, and digital televisions. The AK4430 is offered in a space saving 16pin TSSOP package.

FEATURES †

Sampling Rate Ranging from 8kHz to 192kHz † 128 times Oversampling (Normal Speed Mode) † 64 times Oversampling (Double Speed Mode) † 32 times Oversampling (Quad Speed Mode) † 24-Bit 8 times FIR Digital Filter † Switched-Capacitor Filter with High Tolerance to Clock Jitter † Single Ended 2Vrms Output Buffer † Soft mute † I/F format: 24-bit MSB justified, I2 S † Master clock: 512fs, 768fs or 1152fs (Normal Speed Mode) 256fs or 384fs (Double Speed Mode) 128fs or 192fs (Quad Speed Mode) † THD+N: -91dB † Dynamic Range: 104dB † Automatic Power-on Reset Circuit † Power supply: +3.0 ∼ +3.6V † Ta = -20 to 85°C † Small Package: 16pin TSSOP (6.4mm x 5.0mm)
