Ultralow Noise Op Amp electronic ic chip pc board , AD797BRZ Ultralow Distortion

China Ultralow Noise Op Amp electronic ic chip pc board , AD797BRZ Ultralow Distortion supplier

Large Image :  Ultralow Noise Op Amp electronic ic chip pc board , AD797BRZ Ultralow Distortion

Product Details:

Place of Origin: brand new
Brand Name: AD
Certification: Original Factory Pack
Model Number: AD797BRZ

Payment & Shipping Terms:

Minimum Order Quantity: 20pcs
Price: Negotiation
Packaging Details: please contact me for details
Delivery Time: 1 Day
Payment Terms: T/T, Western Union,PayPal
Supply Ability: 5200PCS
Contact Now
Detailed Product Description
Supply Voltage: ±18 V Input Voltage: ±VS
Differential Input Voltage2: ±0.7 V Storage Temperature Range: −65°C To +125°C
Operating Temperature Range: −40°C To +85°C



Ultralow Noise Op Amp electronic ic chip pc board , AD797BRZ Ultralow Distortion




Ultralow Noise Op Amp electronic ic chip pc board , AD797BRZ Ultralow DistortionAPPLICATIONS

►Professional audio preamplifiers

►IR, CCD, and sonar imaging systems

►Spectrum analyzers

►Ultrasound preamplifiers

►Seismic detectors Σ-Δ

►ADC/DAC buffers



GENERAL DESCRIPTION

The AD797 is a very low noise, low distortion operational amplifier ideal for use as a preamplifier. The low noise of 0.9 nV/√Hz and low total harmonic distortion of −120 dB at audio bandwidths give the AD797 the wide dynamic range necessary for preamps in microphones and mixing consoles. Furthermore, the AD797’s excellent slew rate of 20 V/μs and 110 MHz gain bandwidth make it highly suitable for low frequency ultrasound applications.



The AD797 is also useful in infrared (IR) and sonar imaging applications, where the widest dynamic range is necessary. The low distortion and 16-bit settling time of the AD797 make it ideal for buffering the inputs to Σ-Δ ADCs or the outputs of high resolution DACs, especially when the device is used in critical applications such as seismic detection or in spectrum analyzers. Key features such as a 50 mA output current drive and the specified power supply voltage range of ±5 V to ±15 V make the AD797 an excellent general-purpose amplifier.



ABSOLUTE MAXIMUM RATINGS

Parameter  Ratings
Supply Voltage ±18 V

Internal Power Dissipation @ 25°C1              PDIP

                                                                     SOIC

1.3 W − (TA − 25°C)/θJA

0.9 W (TA − 25°C)/θJA

Input Voltage ±VS
Differential Input Voltage2 ±0.7 V
Output Short-Circuit Duration

Indefinite within maximum

internal power dissipation

Storage Temperature Range

(N, R Suffix)

−65°C to +125°C
Operating Temperature Range −40°C to +85°C

Lead Temperature Range

(Soldering 60 sec)

300°C



TYPICAL PERFORMANCE CHARACTERISTICS

Ultralow Noise Op Amp electronic ic chip pc board , AD797BRZ Ultralow Distortion
