74HC244PW Octal buffer/line driver; 3-state circuitboard integratedcircuit

: Large Image : 74HC244PW Octal buffer/line driver; 3-state circuitboard integratedcircuit

Product Details:

Place of Origin:	brand new
Brand Name:	PH
Certification:	Original Factory Pack
Model Number:	74HC244PW

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	5200PCS

Contact Now

Detailed Product Description

Supply Voltage:	−0.5 ~ +7 V	Input Clamping Current:	±20 MA
Output Clamping Current:	+20 MA	Output Current:	±35 MA
Supply Current:	70 MA
High Light:	circuit board ic , electronic chip board

Octal buffer/line driver; 3-state

74HC244PW Octal buffer/line driver; 3-state circuitboard integratedcircuit Features

■ Octal bus interface

■ Non-inverting 3-state outputs

■ Complies with JEDEC standard no. 7A

■ ESD protection:

◆ HBM EIA/JESD22-A114-C exceeds 2000 V

◆ MM EIA/JESD22-A115-A exceeds 200 V

■ Multiple package options

■ Specified from −40 °C to +85 °C and from −40 °C to +125 °C

General description

The 74HC244; 74HCT244 is a high-speed Si-gate CMOS device and is pin compatible with Low-power Schottky TTL (LSTTL).

The 74HC240; 74HCT240 is similar to the 74HC244; 74HCT244 but has inverting outputs.

The 74HC244; 74HCT244 has octal non-inverting buffer/line drivers with 3-state outputs. The 3-state outputs are controlled by the output enable inputs 1OE and 2OE. A HIGH on nOE causes the outputs to assume a high-impedance OFF-state. The 74HC244; 74HCT244 is identical to the 74HC240; 74HCT240 but has non-inverting outputs

Waveforms

74HC244PW Octal buffer/line driver; 3-state circuitboard integratedcircuit
