PZT3904 NPN General Purpose Amplifier Rectifier Diode

: Large Image : PZT3904 NPN General Purpose Amplifier Rectifier Diode

Product Details:

Place of Origin:	Original
Brand Name:	NSC
Certification:	Original Factory Pack
Model Number:	PZT3904

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	290PCS

Contact Now

Detailed Product Description

Collector-Emitter Voltage:	40 V	Collector-Base Voltage:	60 V
Emitter-Base Voltage:	6.0 V	Collector Current - Continuous:	200 MA
Operating And Storage Junction Temperature Range:	-55 To +150 °C
High Light:	bridge rectifier circuit , signal schottky diode

NPN General Purpose Amplifier

PZT3904 NPN General Purpose Amplifier Rectifier Diode

NPN General Purpose Amplifier

This device is designed as a general purpose amplifier and switch. The useful dynamic range extends to 100 mA as a switch and to 100 MHz as an amplifier. Sourced from Process 23.

Absolute Maximum Ratings*

Symbol	Parameter	Value	Units
VCEO	Collector-Emitter Voltage	40	V
VCBO	Collector-Base Voltage	60	V
VEBO	Emitter-Base Voltage	6.0	V
C	Collector Current - Continuous	200	mA
TJ, Tstg	Operating and Storage Junction Temperature Range	-55 to +150	°C

Typical Characteristics
