DAC5571IDBVT IC +2.7 V to +5.5 V, I2C INTERFACE, VOLTAGE OUTPUT, 8-BIT DIGITAL-TO-ANALOG CONVERTER

: Large Image : DAC5571IDBVT IC +2.7 V to +5.5 V, I2C INTERFACE, VOLTAGE OUTPUT, 8-BIT DIGITAL-TO-ANALOG CONVERTER

Product Details:

Place of Origin:	Original
Brand Name:	TI
Certification:	Original
Model Number:	DAC5571IDBVT

Payment & Shipping Terms:

Minimum Order Quantity:	5 PCS
Price:	0.1USD
Packaging Details:	contact us for more details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	10000PCS/DAY

Contact Now

Detailed Product Description

Features:	Fast Update Rate: 188 KSPS	Voltage:	+2.7-V To +5.5-V
Description:	Power-On Reset To Zero	Temperature:	–40°C To 105°C
Package:	/	Type:	IC
High Light:	circuit board ic , electronic chip board

DAC5571IDBVT IC +2.7 V to +5.5 V, I2C INTERFACE

FEATURES

Micropower Operation: 125 µA @ 3 V

Fast Update Rate: 188 KSPS

Power-On Reset to Zero

+2.7-V to +5.5-V Power Supply

Specified Monotonic by Design

I²C™ Interface up to 3.4 Mbps

On-Chip Output Buffer Amplifier, Rail-to-Rail Operation

Double-Buffered Input Register

Address Support for up to Two DAC5571s

Small 6 Lead SOT 23 Package

Operation From –40°C to 105°C

APPLICATIONS

Process Control

Data Acquistion Systems

Closed-Loop Servo Control

PC Peripherals

Portable Instrumentation

DESCRIPTION

The DAC5571 is a low-power, single-channel, 8-bit

buffered voltage output DAC. Its on-chip precision

output amplifier allows rail-to-rail output swing to be

achieved. The DAC5571 utilizes an I²C-compatible,

two-wire serial interface that operates at clock rates

up to 3.4 Mbps with address support of up to two

DAC5571s on the same data bus.

The output voltage range of the DAC is 0 V to VDD.

The DAC5571 incorporates a power-on-reset circuit

that ensures that the DAC output powers up at zero

volts and remains there until a valid write to the

device takes place. The DAC5571 contains a

power-down feature, accessed via the internal control

device to 50 nA at 5 V.

The low-power consumption of this part in normal

operation makes it ideally suited for portable battery

operated equipment. The power consumption is less

than 0.7 mW at VDD= 5 V reducing to 1 µW in power-down mode.

DAC7571/6571/5571 are 12/10/8-bit, single-channel

I²C DACs from the same family. DAC7574/6574/5574

and DAC7573/6573/5573 are 12/10/8-bit 2

quad-channel I C DACs. Also see DAC8571/8574 for

single/quad-channel, 16-bit I²C DACs.

PIN	NAME	DESCRIPTION
1	^VOUT	Analog output voltage from DAC
2	GND	Ground reference point for all circuitry
3	^VDD	Analog Voltage Supply Input
4	SDA	Serial Data Input
5	SCL	Serial Clock Input
6	A0	Device Address Select
LOT TRACE CODEP	Year(3 = 2003); Month (1–9 = JAN–SEP; A=OCT, B=NOV, C=DEC);LL–Random code generated when assembly is requested
