Product Details:
Payment & Shipping Terms:
|
Ripple Rejection: | 49 DB | Output Noise Voltage: | 40 µV |
---|---|---|---|
Dropout Voltage: | 1.7 V | Input Voltage: 79L05: | -30 V |
Lead Temperature 1.6 Mm (1/16 Inch) From Case For 10 Seconds: | 260°C | Storage Temperature Range: | –65°C To 150°C |
High Light: | bridge rectifier circuit,signal schottky diode |
Negative-Voltage Regulators
description
This series of fixed negative-voltage integrated-circuit voltage regulators is designed for a wide range of applications. These include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, they can be used to control series pass elements to make high-current voltage-regulator circuits. One of these regulators can deliver up to 100 mA of output current. The internal current-limiting and thermal-shutdown features make them essentially immune to overload. When used as a replacement for a zener-diode and resistor combination, these devices can provide effective improvement in output impedance of two orders of magnitude, with lower bias current.
absolute maximum ratings over operating free-air temperature range
(unless otherwise noted)†
Input voltage: 79L05 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -30 V
Operating free-air, case, or virtual junction temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150°C
Lead temperature 1.6 mm (1/16 inch) from case for 10 seconds . . . . . . . . . . . . . . . . . . . . . . . 260°C
Storage temperature range, Tstg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –65°C to 150°C
equivalent schematic
