2N7002LT1G power mosfet ic Power Mosfet Transistor Small Signal MOSFET 60 V, 115 mA, N−Channel SOT−23

: Large Image : 2N7002LT1G power mosfet ic Power Mosfet Transistor Small Signal MOSFET 60 V, 115 mA, N−Channel SOT−23

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	2N7002LT1G

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8600pcs

Contact Now

Detailed Product Description

Drain−Source Voltage:	60 Vdc	Drain−Gate Voltage (RGS = 1.0 M):	60 Vdc
Thermal Resistance, Junction To Ambient:	556 °C/W	TJ:	−55 To +150 °C
Tstg:	−55 To +150 °C	Package:	SOT−23
High Light:	power mosfet ic , silicon power transistors

2N7002L

Small Signal MOSFET 60 V, 115 mA, N−Channel SOT−23

Features

• Pb−Free Packages are Available

V_(BR)DSS

R_DS(on) MAX

I_D MAX

60 V

7.5 @ 10 V,

500 mA

115 mA

MAXIMUM RATINGS

Rating	Symbol	Value	Unit
Drain−Source Voltage	V_DSS	60	Vdc
Drain−Gate Voltage (R_GS = 1.0 M)	V_DGR	60	Vdc
Drain Current − Continuous T_C = 25°C (Note 1) − Continuous T_C = 100°C (Note 1) − Pulsed (Note 2)	I_D I_D I_DM	±115 ±75 ±800	mAdc
Gate−Source Voltage − Continuous − Non−repetitive (tp ≤ 50 μs)	V_GS V_GSM	±20 ±40	Vdc Vpk

Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied, damage may occur and reliability may be affected.

2N7002LT1G power mosfet ic Power Mosfet Transistor Small Signal MOSFET 60 V, 115 mA, N−Channel SOT−23

PACKAGE DIMENSIONS

2N7002LT1G power mosfet ic Power Mosfet Transistor Small Signal MOSFET 60 V, 115 mA, N−Channel SOT−23
