SN74HC21DR DUAL 4-INPUT POSITIVE-AND GATES common ic chips digital ic circuits

: Large Image : SN74HC21DR DUAL 4-INPUT POSITIVE-AND GATES common ic chips digital ic circuits

Product Details:

Place of Origin:	Original
Brand Name:	TI
Certification:	Original Factory Pack
Model Number:	SN74HC21DR

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	290PCS

Contact Now

Detailed Product Description

Supply Voltage Range, VCC:	−0.5 V To 7 V	Input Clamp Current, IIK (VI < 0 Or VI > VCC):	±20 MA
Output Clamp Current, IOK (VO < 0 Or VO > VCC):	±20 MA	Continuous Output Current, IO (VO = 0 To VCC):	±25 MA
Continuous Current Through VCC Or GND:	±50 MA
High Light:	circuit board ic , electronic chip board

SN74HC21DR DUAL 4-INPUT POSITIVE-AND GATES common ic chips digital ic circuits ►Wide Operating Voltage Range of 2 V to 6 V

►Outputs Can Drive Up To 10 LSTTL Loads

►Low Power Consumption, 20-µA Max ICC

►Typical tpd = 11 ns ±4-mA

►Output Drive at 5 V Low

►Input Current of 1 µA Max

description/ordering information

These devices contain two independent 4-input AND gates. They perform the Boolean function Y A • B • C • D or Y A B C D in positive logic. O

SN74HC21DR DUAL 4-INPUT POSITIVE-AND GATES common ic chips digital ic circuits
