Anterwell Technology Ltd.
Large Original stock of IC Electronics Components, Transistors, Diodes etc.
High Quality, Reasonable Price, Fast Delivery.
Product Details:
Payment & Shipping Terms:
|
Temperature Range: | -55°C To +150°C | Typical Thermal Resistance: | 50mA |
---|---|---|---|
Voltage: | 70V | Forward Surge Current: | 200mW |
Package: | SOP-4 | Factory Package: | REEL |
High Light: | electronics ic chip,integrated circuit ic |
FOD814 Series, FOD617 Series, FOD817 Series 4-Pin High Operating Temperature Phototransistor Optocouplers
Features
■ AC input response (FOD814 only)
■ Applicable to Pb-free IR reflow soldering
■ Compact 4-pin package
■ Current transfer ratio in selected groups:
FOD617A: 40–80% FOD817: 50–600% FOD617B: 63–125%
FOD817A:80–160% FOD617C:100–200% FOD817B: 130–260%
FOD617D:160–320% FOD817C:200–400% FOD814: 20–300%
FOD817D:300–600% FOD814A: 50–150%
■ C-UL, UL and VDE approved
■ High input-output isolation voltage of 5000Vrms
■ Minimum BVCEO of 70V guaranteed
■ Higher operating temperatures (versus H11AXXX counterparts)
Applications
FOD814 Series
■ AC line monitor ■ Unknown polarity DC sensor ■ Telephone line interface
FOD617 and FOD817 Series
■ Power supply regulators ■ Digital logic inputs ■ Microprocessor inputs
Description
The FOD814 consists of two gallium arsenide infrared emitting diodes, connected in inverse parallel, driving a silicon phototransistor output in a 4-pin dual in-line package. The FOD617/817 Series consists of a gallium arsenide infrared emitting diode driving a silicon phototransistor in a 4-pin dual in-line package.
