Product Details:
Payment & Shipping Terms:
|
Supply Voltage Range: | −0.5 V To 7 V | Input Voltage Range: | −0.5 V To 7 V |
---|---|---|---|
Output Voltage Range: | −0.5 V To VCC + 0.5 V | Input Clamp Current: | −20 MA |
Output Clamp Current: | −50 MA | Storage Temperature Range: | −65 °C To 150°C |
High Light: | electronics ic chip,integrated circuit ic |
SN54LV165A, SN74LV165A
PARALLEL-LOAD 8-BIT SHIFT REGISTERS
SN54LV165A . . . J OR W PACKAGE SN74LV165A . . . D, DB, DGV, NS, OR PW PACKAGE (TOP VIEW)
SN74LV165A . . . RGY PACKAGE (TOP VIEW)
SN54LV165A . . . FK PACKAGE (TOP VIEW)
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
Supply voltage range, VCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −0.5 V to 7 V
Input voltage range, VI (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −0.5 V to 7 V
Voltage range applied to any output in the high-impedance
or power-off state, VO (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −0.5 V to 7 V
Output voltage range, VO (see Notes 1 and 2) . . . . . . . . . . . . . . . . . . . . . . . . . . −0.5 V to VCC + 0.5 V
Input clamp current, IIK (VI < 0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −20 mA
Output clamp current, IOK (VO < 0) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −50 mA
Continuous output current, IO (VO = 0 to VCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±25 mA
Continuous current through VCC or GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±50 mA
Package thermal impedance, θJA (see Note 3): D package . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73°C/W
(see Note 3): DB package . . . . . . . . . . . . . . . . . . . . . . . . . . 82 °C/W
(see Note 3): DGV package . . . . . . . . . . . . . . . . . . . . . . . 120 °C/W
(see Note 3): NS package . . . . . . . . . . . . . . . . . . . . . . . . . . 67 °C/W
(see Note 3): PW package . . . . . . . . . . . . . . . . . . . . . . . . 108 °C/W
(see Note 4): RGY package . . . . . . . . . . . . . . . . . . . . . . . . 39 °C/W
Storage temperature range, Tstg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . −65 °C to 150°C
†Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES: 1. The input and output negative-voltage ratings may be exceeded if the input and output current ratings are observed.
2. This value is limited to 5.5 V maximum.
3. The package thermal impedance is calculated in accordance with JESD 51-7. 4. The package thermal impedance is calculated in accordance with JESD 51-5.
logic diagram (positive logic)
typical shift, load, and inhibit sequences
