Product Details:
Payment & Shipping Terms:
|
| Cathode To Anode Voltage: | 25 V | Reverse Breakdown Current: | -100 To +150 MA |
|---|---|---|---|
| Reference Input Current Range: | -0.05 To +10 MA | Power Dissipation 1) SOT23-3: | 360 MW |
| Storage Temperature: | -65 To +150 °C | ||
| Highlight: | bridge rectifier circuit,signal schottky diode |
||
■ ADJUSTABLE OUTPUT VOLTAGE 2.5 to 24V
■ SEVERAL PRECISION @ 25°C ±2%, ±1% and ±0.5%
■ SINK CURRENT CAPABILITY 1 to 100mA
■ INDUSTRIAL TEMPERATURE RANGE: -40 to +105°C
■ PERFORMANCES COMPATIBLE WITH INDUSTRY STANDARD TL431
DESCRIPTION
The TS2431 is a programmable shunt voltage reference with guaranteed temperature stability over the entire temperature range of operation (-40 to +105°C). The output voltage may be set to any value between 2.5V and 24V with an external resistor bridge.
Available in SOT23-3 surface mount package, it can be designed in applications where space saving is a critical issue.
APPLICATION
■ Computers
■ Instrumentation
■ Battery chargers
■ Switch Mode Power Supply
■ Battery operated equipments
ABSOLUTE MAXIMUM RATINGS
| Symbol | Parameter | Value | Unit |
| Vka | Cathode to Anode voltage | 25 | V |
| IK | Reverse Breakdown Current | -100 to +150 | mA |
| IREF | Reference input current range | -0.05 to +10 | mA |
| Pd | Power Dissipation 1) SOT23-3 | 360 | mW |
| Tstd | Storage Temperature | -65 to +150 | °C |
| ESD | Human Body Model (HBM) | 2 | kV |
| Machine Model (MM) | 200 | V | |
| TLEAD | Lead Temperatue (soldering, 10 seconds) | 260 | 260 °C |
