Product Details:
Payment & Shipping Terms:
|
| Voltage: | 2.4 To 75 V | Temperature: | −65 To +200°C |
|---|---|---|---|
| Output Current: | 250mA | Main Line:: | Ic,module,transistor,diodes,capacitor,resistor Etc |
| Package: | SOD80C | Factory Pack: | 2500/Tape & Reel |
| Datacode: | 2016+ | Resistance: | 500mW |
| High Light: | diode rectifier circuit,bridge rectifier circuit |
||
BZV55 Series
ZENER DIODES
Features
• Total power dissipation: max. 500 mW
• Two tolerance series: ±2%, and approx. ±5%
• Working voltage range: nom. 2.4 to 75 V (E24 range)
• Non-repetitive peak reverse power dissipation: max. 40 W. APPLICATIONS
• Low voltage stabilizers or voltage references.
DESCRIPTION
Low-power voltage regulator diodes in small hermetically sealed glass SOD80C SMD packages.
The diodes are available in the normalized E24 ±2% (BZV55-B) and approx. ±5% (BZV55-C) tolerance range.
The series consists of 37 types with nominal working voltages from 2.4 to 75 V.
MAXIMUM RATINGS
| Rating | Symbol | Value | Unit |
| DC Power Dissipation @ TL = 75°C, Measured Zero Lead Length (Note 1) Derate above 75°C Thermal Resistance, Junction−to−Lead |
PD
RJL |
1.5 20
50 |
W mW/°C
°C/W |
| DC Power Dissipation @ TA = 25°C (Note 2) Derate above 25°C Thermal Resistance, Junction−to−Ambient |
PD
RJA |
0.5 4 250 |
W mW/°C °C/W |
| Operating and Storage Temperature Range | TJ, Tstg | −65 to +200 | °C |
