Product Details:
Payment & Shipping Terms:
|
Power Supply Voltage: | 40 V | Comparator Input Voltage Range: | -0.3 ~ +40 V |
---|---|---|---|
Switch Collector Voltage: | 40 V | Driver Collector Current: | 100 MA |
Maximum Junction Temperature: | +150 °C | Storage Temperature Range: | -65 ~ +150 °C |
High Light: | electronics ic chip,integrated circuit components |
AP34063
UNIVERSAL DC/DC CONVERTER
Features
• Operation from 3.0V to 40V Input
• Low Standby Current
• Current Limiting
• Output Switch Current to 1.6A
• Output Voltage Adjustable
• Frequency Operation to 100 kHz
• Precision 2% Reference
• Lead Free packages: SOP-8L and PDIP-8L (Note 1)
• SOP-8L: Available in “Green” Molding Compound (No Br, Sb)
• Lead Free Finish/RoHS Compliant (Note 2)
Description
The AP34063 Series is a monolithic control circuit containing the primary functions required for DC-to-DC converters. These devices consist of an internal temperature compensated reference, comparator, controlled duty cycle oscillator with an active current limit circuit, driver and high current output switch. This series is specifically designed for incorporating in Step-Down and Step-Up and Voltage-Inverting applications with a minimum number of external components.
Maximum Ratings
Symbol | Parameter | Value | Unit | |
VCC | Power Supply Voltage | 40 | V | |
VIR | Comparator Input Voltage Range | -0.3 ~ +40 | V | |
VC (switch) | Switch Collector Voltage | 40 | V | |
VE (switch) | Switch Emitter Voltage (VPin 1 = 40V) | 40 | V | |
VCE (switch) | Switch Collector to Emitter Voltage | 40 | V | |
VC (driver) | Driver Collector Voltage | 40 | V | |
IC (driver) | Driver Collector Current | 100 | mA | |
ISW | Switch Current | 1.6 | A | |
PD | Power Dissipation and Thermal Characteristics | SOP: TA = 25°C | 600 | mW |
PDIP: TA = 25°C | 1.25 | W | ||
θJA | Thermal Resistance | 160 | °C/W | |
TMJ | Maximum Junction Temperature | +150 | °C | |
TOP | Operating Junction Temperature Range | 0 ~ +105 | °C | |
Tstg | Storage Temperature Range | -65 ~ +150 | °C |
Notes:
4. Maximum package power dissipation limits must be observed.
5. Low duty cycle pulse techniques are used during test to maintain junction temperature as close to ambient temperature as possible.
Representative Schematic Diagram
Package Information (All Dimensions in mm)
(1) SOP-8L
(2) PDIP-8L
