M95160-WMN6TP Electronic components 16-Kbit serial SPI bus EEPROM with high-speed clock

16-Kbit serial SPI bus EEPROM with high-speed clock

  Features

• Compatible with the Serial Peripheral Interface (SPI) bus • Memory array

– 16 Kb (2 Kbytes) of EEPROM

– Page size: 32 bytes

• Write

– Byte Write within 5 ms

– Page Write within 5 ms

• Write Protect: quarter, half or whole memory array

• High-speed clock: 20 MHz

• Single supply voltage:

– 2.5 V to 5.5 V for M95160-W

– 1.8 V to 5.5 V for M95160-R

– 1.7 V to 5.5 V for M95160-DF

• Operating temperature range:

from -40°C up to +85°C

• Enhanced ESD protection

• More than 4 million Write cycles

• More than 200-year data retention

• Packages – RoHS compliant and halogen-free

Description

The M95160 devices are Electrically Erasable PROgrammable Memories (EEPROMs) organized as 2048 x 8 bits, accessed through the SPI bus

The M95160-W can operate with a supply voltage from 2.5 V to 5.5 V, the M95160-R can operate with a supply voltage from 1.8 V to 5.5 V, and the M95160-DF can operate with a supply voltage from 1.7 V to 5.5 V, over an ambient temperature range of -40 °C / +85 °C.

The M95160-D offers an additional page, named the Identification Page (32 bytes). The Identification Page can be used to store sensitive application parameters which can be (later) permanently locked in Read-only mode.

Table 1. Signal names
