ACS712TELC-05B Resistance Fully Integrated Hall Effect-Based Linear Current Sensor

: Large Image : ACS712TELC-05B Resistance Fully Integrated Hall Effect-Based Linear Current Sensor

Product Details:

Place of Origin:	Original
Brand Name:	ALLEGRO
Certification:	Original
Model Number:	ACS712TELC-05B

Payment & Shipping Terms:

Minimum Order Quantity:	5 PCS
Price:	0.1USD
Packaging Details:	contact us for more details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	10000PCS/DAY

Contact Now

Detailed Product Description

Features:	Low-noise Analog Signal Path	Description:	Economical And Precisesolutions
Package:	8 Pin SOIC	Optimized Range:	±5
Sensitivity:	185	Type:	Resistance
High Light:	electronics ic chip , integrated circuit components

ACS712TELC-05B Resistance

Features and Benefits

1.Low-noise analog signal path 2.Device bandwidth is set via the new FILTER pin 3.5 µs output rise time in response to step input current

4.50 kHz bandwidth 5.Total output error 1.5% at TA= 25°C, and 4% at –40°C to 85°C 6.Small footprint, low-profile SOIC8 package

7.1.2 mΩ internal conductor resistance 8.2.1 kV RMS 9.minimum isolation voltage from pins 1-4 to pins 5-8 10.5.0 V, single supply operation

11.66 to 185 mV/A output sensitivity 12.Output voltage proportional to AC or DC currents 13.Factory-trimmed for accuracy 14.Extremely stable output offset voltage 15.Nearly zero magnetic hysteresis 16.Ratiometric output from supply voltage

Description

The Allegro® ACS712 provides economical and precise solutions for AC or DC current sensing in industrial, automotive, commercial, and communications systems. The device package allows for easy implementation by the customer. Typical applications include motor control, load detection and management, switched-mode power supplies, and overcurrent fault protection.

The device consists of a precise, low-offset, linear Hall sensor circuit with a copper conduction path located near the surface of the die. Applied current flowing through this copper conduction path generates a magnetic field which is sensed by the integrated Hall IC and converted into a proportional voltage. Device accuracy is optimized through the close proximity of the magnetic signal to the Hall transducer. A precise, proportional voltage is provided by the low-offset,chopper-stabilized BiCMOS Hall IC, which is programmed for accuracy after packaging.The output of the device has a positive slope (>V IOUT(Q))

when an increasing current flows through the primary copper conduction path (from pins 1 and 2, to pins 3 and 4), which is the path used for current sensing. The internal resistance of this conductive path is 1.2 mΩ typical, providing low power

Application

1. The ACS712 outputs an analog signal, VOUT. that varies linearly with the uni- or bi-directional AC or DC primary sensed current, IP, within the range specified. CF is recommended for noise management, with values that depend on the application.

Number	Name	Description
1 and 2	IP+	Terminals for current being sensed; fused internally
3 and 4	IP–	Terminals for current being sensed; fused internally
5	GND	Signal ground terminal
6	FILTER	Terminal for external capacitor that sets bandwidth
7	VIOUT	Analog output signal
8	VCC	Device power supply termina
