Dual Surface Mount Switching Diode Three Terminals Smd Switching Diode High Speed Switching Diodes Bav70

: Large Image : Dual Surface Mount Switching Diode Three Terminals Smd Switching Diode High Speed Switching Diodes Bav70

Product Details:

Place of Origin:	China
Brand Name:	PHILIPS
Certification:	Original Factory Pack
Model Number:	BAV70

Payment & Shipping Terms:

Minimum Order Quantity:	3000pcs
Price:	negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T Western Union,PayPal
Supply Ability:	30000PCS

Contact Now

Detailed Product Description

Reverse Voltage:	70 V	Forward Current:	200 MA
Peak Forward Surge Current:	500 MA	Power Dissipation:	225 MW
Thermal Resistance Junction To Ambient Air:	556 O C/W	Junction Temperature:	150 O C
High Light:	diode rectifier circuit , bridge rectifier circuit

BAW56/BAV70/BAV99 Plastic-Encapsulate Switching Diodes

Features Dual Surface Mount Switching Diode Three Terminals Smd Switching Diode High Speed Switching Diodes Bav70

►Fast switching speed

►Surface mount package ideally suited for automatic insertion

►For general purpose switching applications

►High conductance Me

Mechanical Data

Case: SOT-23, Molded plastic

Terminals: Solderable per MIIL-STD-202, Method 208

Polarity: See diagram

Marking: BAW56: A1, BAV70: A4, BAV99: A7

Weight: 0.008 gram (approx.) SOT

Dual Surface Mount Switching Diode Three Terminals Smd Switching Diode High Speed Switching Diodes Bav70

Type Number	Symbol	BAW56/BAV70/BAV99	Units
Reverse Voltage	V_R	70	V
Forward Current	I_F	200	mA
Peak Forward Surge Current	I_FM(surge)	500	mA
Power Dissipation	P_D	225	mW
Thermal Resistance Junction to Ambient Air	R_θJA	556	o C/W
Junction Temperature	T_J	150	o C
Storage Temperature Range	T_STG	-55 to 150	o C
