Transistor Power Driver Stage Amplifier Applications Complementary To 2sc4793 A1837

: Large Image : Transistor Power Driver Stage Amplifier Applications Complementary To 2sc4793 A1837

Product Details:

Place of Origin:	Original
Brand Name:	TOSHIBA
Certification:	Original Factory Pack
Model Number:	A1837

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	5200PCS

Contact Now

Detailed Product Description

VCBO:	-230 V	VCEO:	−230 V
VEBO:	−5 V	IC:	−1 A
IB:	−0.1 A
High Light:	multi emitter transistor , silicon power transistors

TOSHIBA Transistor Silicon PNP Epitaxial Type

Power Amplifier Applications Transistor Power Driver Stage Amplifier Applications Complementary To 2sc4793 A1837

Driver Stage Amplifier Applications

• High transition frequency: fT = 70 MHz (typ.)

• Complementary to 2SC4793

Note:

Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings. Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook (“Handling Precautions”/Derating Concept and Methods) and individual reliability data (i.e. reliability test report and estimated failure rate, etc).

Absolute Maximum Ratings (Tc = 25°C)

Characteristics	Symbol	Rating	Unit
Collector-base voltage	V_CBO	−230	V
Collector-emitter voltage	V_CEO	−230	V
Emitter-base voltage	V_EBO	−5	V
Collector current	I_C	−1	A
Base current	I_B	-0.1	A
Collector power dissipation Ta = 25°C Tc = 25°C	P_C	2.0	W
Collector power dissipation Ta = 25°C Tc = 25°C	P_C	20	W
Junction temperature	Tj	150	°C
Storage temperature range	Tstg	−55 to 150	°C
