Feature 1: | IsoPower Integrated, Isolated Dc-to-dc Converter | Feature 2: | Regulated 3.3 V Or 5 V Output |
---|---|---|---|
Feature 3: | Up To 500 MW Output Power | Feature 4: | Quad Dc-to-25 Mbps (NRZ) Signal Isolation Channels |
Feature 5: | Schmitt Trigger Inputs | Feature 6: | 16-lead SOIC Package With 7.6 Mm Creepage |
High Light: | circuit board ic,electronic components ic |
FEATURES FUNCTIONAL BLOCK DIAGRAMS
isoPower integrated, isolated dc-to-dc converter
Regulated 3.3 V or 5 V output
Up to 500 mW output power
Quad dc-to-25 Mbps (NRZ) signal isolation channels
Schmitt trigger inputs
16-lead SOIC package with 7.6 mm creepage
High temperature operation: 105°C
High common-mode transient immunity: >25 kV/μs
Safety and regulatory approvals (pending)
UL recognition
5000 V rms for 1 minute per UL1577
CSA Component Acceptance Notice #5A
IEC 60950-1: 600 V rms (reinforced)
IEC 60601-1: 250 V rms (reinforced)
VDE certificate of conformity
DIN V VDE V 0884-10 (VDE V 0884-10):2006-12
VIORM = 560 V peak
APPLICATIONS
RS-232/RS-422/RS-485 transceivers
Medical isolation
AC/dc power supply startup bias and gate drives
Isolated sensor interface
GENERAL DESCRIPTION
The ADuM640x1 devices are quad-channel digital isolators with
isoPower®, an integrated, isolated dc-to-dc converter. Based on
the Analog Devices, Inc., iCoupler® technology, the dc-to-dc
converter provides up to 500 mW of regulated, isolated power at
either 5.0 V or 3.3 V from a 5.0 V input supply, or 3.3 V from a
3.3 V supply at the power levels shown in Table 1. This eliminates
the need for a separate, isolated dc-to-dc converter in low power,
isolated designs. The iCoupler chip scale transformer technology
is used to isolate the logic signals and for the magnetic components
of the dc-to-dc converter. The result is a small form factor, total
isolation solution.
The ADuM640x isolators provide four independent isolation
channels in a variety of channel configurations and data rates
(see the Ordering Guide for more information).
isoPower uses high frequency switching elements to transfer
power through its transformer. Special care must be taken
during printed circuit board (PCB) layout to meet emissions
standards. Refer to the AN-0971 application note for board
layout recommendations at www.analog.com.
