Suppressor Transient Voltage Suppressors Peak Pulse Power 1500W Breakdown Voltage 6.8 to 550V

: Large Image : Suppressor Transient Voltage Suppressors Peak Pulse Power 1500W Breakdown Voltage 6.8 to 550V

Product Details:

Place of Origin:	Original
Brand Name:	VISHAY
Certification:	Original Factory Pack
Model Number:	1.5KE36A

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	5200PCS

Contact Now

Detailed Product Description

VBR Uni-directional:	6.8 V To 540 V	VBR Bi-directional:	6.8 V To 440 V
PPPM:	PPPM 1500 W	PD:	6.5 W
IFSM (uni-directional Only):	200 A
High Light:	diode rectifier circuit , bridge rectifier circuit

TRANSZORB® Transient Voltage Suppressors

Suppressor Transient Voltage Suppressors Peak Pulse Power 1500W Breakdown Voltage 6.8 to 550V

FEATURES

• Glass passivated chip junction

• Available in uni-directional and bi-directional

• 1500 W peak pulse power capability with a 10/1000 µs waveform,

repetitive rate (duty cycle): 0.01 %

• Excellent clamping capability

• Very fast response time

• Low incremental surge resistance

• Solder dip 260 °C, 40 s

• Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC

TYPICAL APPLICATIONS

Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial, automotive and telecommunication.

MECHANICAL DATA

Case:

Molded epoxy body over passivated junction Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS compliant, commercial grade Base P/NHE3 - RoHS compliant, high reliability/ automotive grade (AEC Q101 qualified)

Terminals:

Matte tin plated leads, solderable per J-STD-002 and JESD22-B102 E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix meets JESD 201 class 2 whisker test

Note: • 1.5KE250 ~ 1.5KE540A and 1.5KE250C ~ 1.5KE440CA for commercial grade only

Polarity:

For uni-directional types the color band denotes cathode end, no marking on bi-directional types

PRIMARY CHARACTERISTICS
V_BR^{uni-directional 6.8 V to 540 V}	6.8 V to 540 V
V_BR ^{bi-directional 6.8 V to 440 V}	6.8 V to 440 V
P_PPM	1500 W
P_D	6.5 W
I_FSM⁽^{uni-directional only)}	200 A
T_J ^max.	TJ max. 175 °C
