Octal buffer / line driver Integrated Circuit Chip 3-state 74HC541PW

: Large Image : Octal buffer / line driver Integrated Circuit Chip 3-state 74HC541PW

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	74HC541PW

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	290pcs

Contact Now

Detailed Product Description

Feature 1:	Non-inverting Outputs	Output Capability:	Bus Driver
Icc Category:	MSI	QUICK REFERENCE DATA:	GND = 0 V; Tamb = 25 °C; Tr = Tf = 6 Ns
Octal Buffer/line Driver:	3-state	PHILIPS:	NXP SEMICONDUCTORS
High Light:	electronics ic chip , integrated circuit ic

FEATURES

• Non-inverting outputs

• Output capability: bus driver

• I_CC category: MSI

GENERAL DESCRIPTION

The 74HC/HCT541 are high-speed Si-gate CMOS devices and are pin compatible with low power Schottky TTL (LSTTL). They are specified in compliance with JEDEC standard no. 7A.

The 74HC/HCT541 are octal non-inverting buffer/line drivers with 3-state outputs. The 3-state outputs are controlled by the output enable inputs OE₁and OE₂. A HIGH on OE_n causes the outputs to assume a high impedance OFF-state.

The “541” is identical to the “540” but has non-inverting outputs.

PIN DESCRIPTION

PIN NO.

SYMBOL

NAME AND FUNCTION

1, 19

2, 3, 4, 5, 6, 7, 8, 9

18, 17, 16, 15, 14, 13, 12, 11

OE₁, OE₂

A₀ to A₇

GND

Y₀ to Y₇

V_CC

output enable input (active LOW)

data inputs

ground (0 V)

bus outputs

positive supply voltage

Octal buffer / line driver Integrated Circuit Chip 3-state 74HC541PW
