Product Details:
Payment & Shipping Terms:
|
Drain To Source Voltage: | 100 V | Gate To Source Voltage: | ±20 V |
---|---|---|---|
Continuous (T 80 A C < 111oC, VGS = 10V): | 80 A | Continuous (Tamb = 25oC, VGS = 10V, RθJA = 43oC/W): | 12 A |
Single Pulse Avalanche Energy (Note 1): | 393 MJ | Power Dissipation: | 310 W |
High Light: | power mosfet ic,multi emitter transistor |
FDB3632 / FDP3632 / FDI3632
N-Channel PowerTrench® MOSFET 100V, 80A, 9mΩ
Features
• rDS(ON) = 7.5mΩ (Typ.), VGS = 10V, ID = 80A
• Qg(tot) = 84nC (Typ.), VGS = 10V
• Low Miller Charge
• Low QRR Body Diode
• UIS Capability (Single Pulse and Repetitive Pulse)
• Qualified to AEC Q101 Formerly developmental type 82784
Applications
• DC/DC converters and Off-Line UPS
• Distributed Power Architectures and VRMs
• Primary Switch for 24V and 48V Systems
• High Voltage Synchronous Rectifier
• Direct Injection / Diesel Injection Systems
• 42V Automotive Load Control
• Electronic Valve Train Systems
