Octal bus transceiver 3-state Octal bidirectional bus interface 74HC245PW

General description

The 74HC245; 74HCT245 is a high-speed Si-gate CMOS device and is pin compatible with Low-Power Schottky TTL (LSTTL). The 74HC245; 74HCT245 is an octal transceiver featuring non-inverting 3-state bus compatible outputs in both send and receive directions. The 74HC245; 74HCT245 features an output enable input (OE) for easy cascading and a send/receive input (DIR) for direction control. OE controls the outputs so that the buses are effectively isolated. The 74HC245; 74HCT245 is similar to the 74HC640; 74HCT640 but has true (non-inverting) outputs.

Features

■ Octal bidirectional bus interface

■ Non-inverting 3-state outputs

■ Multiple package options

■ Complies with JEDEC standard no. 7A

■ ESD protection:

◆ HBM EIA/JESD22-A114-B exceeds 2000 V

◆ MM EIA/JESD22-A115-A exceeds 200 V

■ Specified from −40 °C to +85 °C and from −40 °C to +125 °C

Waveforms
