Product Details:
Payment & Shipping Terms:
|
| Drain-to-Source Voltage: | 100 V | Gate Charge Total (10 V): | 27 NC |
|---|---|---|---|
| Gate Charge Gate To Drain: | 4.9 NC | Drain-to-Source On Resistance: | 8.7 MΩ |
| Threshold Voltage: | 2.8 V | ||
| High Light: | power mosfet ic,silicon power transistors |
||
FEATURES
• Ultra-Low Qg and Qgd
• Low Thermal Resistance
• Avalanche Rated
• Pb-Free Terminal Plating
• RoHS Compliant
• Halogen Free
• SON 5-mm × 6-mm Plastic Package
APPLICATIONS
• Primary Side Telecom
• Secondary Side Synchronous Rectifier
• Motor Control
DESCRIPTION
This 100 V, 7.8 mΩ, SON 5 mm x 6 mm NexFET™
power MOSFET is designed to minimize losses in
power conversion applications.
Q5A Tape and Reel Information
Notes:
1. 10-sprocket hole-pitch cumulative tolerance ±0.2
2. Camber not to exceed 1 mm in 100 mm, noncumulative over 250 mm
3. Material: black static-dissipative polystyrene
4. All dimensions are in mm (unless otherwise specified)
5. A0 and B0 measured on a plane 0.3 mm above the bottom of the pocket
