Electronics 2A Rectifier Diode BAT54A Surface Mount Schottky Barrier Diode

: Large Image : Electronics 2A Rectifier Diode BAT54A Surface Mount Schottky Barrier Diode

Product Details:

Place of Origin:	China
Brand Name:	Diodes
Certification:	Original Factory Pack
Model Number:	BAT54A

Payment & Shipping Terms:

Minimum Order Quantity:	3000pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T , Western Union,PayPal
Supply Ability:	50000PCS

Contact Now

Detailed Product Description

Shipment::	DHL, Fedex, TNT, EMS Etc	Main Line::	Ic,module,transistor,diodes,capacitor,resistor Etc
Temperature Range:	-65 To +125 ℃	Current:	300 MA
Factory Pack:	3000pcs/Reel	Package:	Sot-23
High Light:	diode rectifier circuit , signal schottky diode

Electronics 2A Rectifier Diode BAT54A Surface Mount Schottky Barrier Diode

BAT54A SURFACE MOUNT SCHOTTKY BARRIER DIODE

Features Electronics 2A Rectifier Diode BAT54A Surface Mount Schottky Barrier Diode

.Low Turn-on Voltage

.Fast Switching

.PN Junction Guard Ring for Transient

and ESD Protection

Mechanical Data

Case: SOT-23, Molded Plastic

Case material - UL Flammability Rating Classification 94V-0

Terminals: Solderable per MIL-STD-202, Method 208

Polarity: See Diagrams Below

Weight: 0.008 grams (approx.)

Moisture sensitivity: Level 1 per J-STD-020A

Ordering Information: See Page 3

Marking Code: See Diagrams Below

Maximum Ratings @ TA = 25 ℃ unless otherwise specified

Characteristic	Symbol	Value	Unit
Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage	VRRM VRWM VR	30	V
Forward Continuous Current (Note 2)	IF	200	mA
Repetitive Peak Forward Current	IFRM	300	mA
Forward Surge Current @ t < 1.0s	IFSM	600	mA
Power Dissipation (Note 2)	Pd	200	Mw
Thermal Resistance, Junction to Ambient Air (Note 2)	RJA	500	℃/W
Operating and Storage Temperature Range	Tj, TSTG	-65 to +125	℃

Electrical Characteristics

@ TA = 25 ℃ unless otherwise specified

Characteristic	Symbol	Min	Typ	Max	Unit	Test Condition
Reverse Breakdown Voltage	V(BR)R	30	-	-	V	IRS = 100A
Forward Voltage	VF	-	-	240 320 400 500 1000	mV	IF = 0.1mA IF = 1mA IF = 10mA IF = 30mA IF = 100mA
Reverse Leakage Current	Ir	-	-	2.0	UA	VR = 25V
Total Capacitance	Cr	-	-	10	pF	VR = 1.0V, f = 1.0MHz
Reverse Recovery Time	Trr	-	-	5.0	nS	IF = 10mA through IR = 10mA to IR = 1.0mA RL = 100
