SB560-E3-73 Schottky Barrier Rectifiers Reverse Voltage 20 to 100V Forward Current 5.0A
Feature & Dimensions
Plastic package has Underwriters Laboratory Flammability Classification 94V-0
Low power loss,high efficiency
For use in low voltage high frequency inverters, free wheeling,and polarity protection applications Guarding for over voltage protection
High temperature soldering guaranteed: 260°C/10 seconds at terminals
IEC61000-4-2 ESD Air Contact≥±15KV
Mechanical Data
Case: JEDEC DO-201AD, molded plastic over sky die Terminals: Plated axial leads, solderable per MIL-STD-750, Method 2026 Polarity: Color band denotes cathode end Mounting Position: Any
Weight: 0.038oz., 1.03 g Handling precautin:None
1.Electrical Characteristic Maximum & Thermal Characteristics Ratings at 25°C ambient temperature unless otherwise specified.
| Parameter Symbol | symbol | SB520- E | SB530-E | SB540-E | SB550-E | SB560-E | SB580-E | SB5100-E | Unit |
|---|---|---|---|---|---|---|---|---|---|
| device marking code | SB520 ESD | SB530 ESD | SB540 ESD | SB550 ESD | SB560 ESD | SB580 ESD | SB5100 ESD | ||
| Maximum repetitive peak reverse voltage | VRRM | 20 | 30 | 40 | 50 | 60 | 80 | 100 | V |
| Maximum RMS voltage | VRMS | 14 | 21 | 28 | 35 | 42 | 56 | 70 | V |
| Maximum DC blocking voltage | VDC | 20 | 30 | 40 | 50 | 60 | 80 | 100 | V |
| Maximum average forward rectified curren 0.375" (9.5mm) lead length (See fig. 1) | IF(AV) | 5.0 | A | ||||||
| Peak forward surge current 8.3ms single half sinewave superimposed on rated load (JEDEC Method) | IFSM | 150 | A | ||||||
| Operating junction and storage temperature range | TJ, TSTG | –40 to +150 | °C | ||||||
Electrical Characteristics Ratings at 25°C ambient temperature unless otherwise specified
| Parameter Symbol | symbol | SB520-E | SB530-E | SB540-E | SB550- E | SB560-E | SB580-E | SB5100-E | Unit |
|---|---|---|---|---|---|---|---|---|---|
| Maximum instantaneous forward voltage at 5.0A | VF | 0.50 | 0.70 | 0.84 | V | ||||
| Maximum DC reverse current TA = 25°C at rated DC blocking voltage TA = 125°C | IR |
1 20 |
mA | ||||||
| thermal resistance, junction to ambient | RθJA | 35 | °C/W | ||||||
| Typical junction capacitance at 4.0V, 1MHz | CJ | 500 | 380 | PF | |||||
