Product Details:
Payment & Shipping Terms:
|
| Voltage Range 1: | 10 V To 270 V | Power Dissipation: | 3W |
|---|---|---|---|
| Maximum Reverse Leakage Current: | 1 UA | MAX Operating Temperature: | +150°C |
| MIN Operating Temperature: | - 65°C | Weigh: | 0.002 Ounces, 0.064 Grams |
| Highlight: | diode rectifier circuit,signal schottky diode |
||
BZG03C12TR Zener Diode
FEATURES
High reliability
Voltage range 10 V to 270 V
Fits onto 5 mm SMD footpads
Wave and reflow solderable
Glass passivated junction
MECHANICAL DATA
Case:JEDEC DO-214AC(SMA)
Terminals: Solderable per MIL- STD-202,Method 208
Polarity: Color band denotes cathods end
Weight: 0.002 ounces, 0.064 grams
Mounting position: any
Maximum Ratings and Thermal Characteristics
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Power dissipation at TA=100℃ | Ptot | 3.0 | W |
| Forward voltage @IF=500mA | VF | 1.2 | V |
|
Maximum thermal resistance junction to ambient |
RθJA | 150 | K/W |
|
Peak reverse power dissipation(non-repetitive) tp=100µs square wave |
PZSM | 600 | W |
| Junction temperature | TJ | -65 to +150 | ℃ |
| Storage temperature range | TSTG | -65 to +150 | ℃ |
